Adding GitHub Libraries in KiCad (English)

KiCad has an open source library, which is one of the advantage of it. Every week, KiCad’s library is updated through GitHub from KiCad. This article is dedicated to show how to install additional libraries for KiCad, and adding third-party libraries such as Digi-Key or Sparkfun Electronics for example. Digi-Key and Sparkfun’s libraries can be accessed through the links below:

  1. SparkFun Library:
  2. Digi-Key Library:

As an example, this article will show how to add Sparkfun library on KiCad 5.0.0 for Ubuntu 18.04

Cloning the Library via GitHub

Library can be accessed through Github, where almost everyone can share their library and contribute to the open source library in GitHub. If there are new additions in the library, the version renewal using Git will be much easier and won’t take much hard disk space, as only the additional files will be downloaded and not the entire files. to download Sparkfun library in GitHub, make sure you have the git package and execute the command below:

$ git clone

After you finish the download, you can see several folders which contained Library and other supplementary folders, and also additional files. The result of downloading the library is as shown in Picture 1

Screenshot from 2018-08-13 21-56-02
Picture 1. Result of cloning KiCad’s library repository from Sparkfun

Adding the Library in KiCad

After downloading the library, the next thing is to open KiCad program to add the downloaded library. But before that, make a new Project by using File > New > New Project

Access “Environment Variable Configuration” in Preferences > Configure Paths. Add new Environment Variable using the “Add” button, then give the name “KICAD_SPARKFUN_SYMBOL” and show the folder location using the “Browse” button.

Screenshot from 2018-08-13 22-13-56
Picture 2. Adding Environment Variable

After adding Environment Variable, open Eeschema (Schematic Editor) and open Preferences > Manage Symbol Libraries. Press “Browse Libraries…” and select all desired library before pressing open

Screenshot from 2018-08-13 22-22-33
Picture 3. Adding Library Symbol to Create Schematics

Open Pcbnew (PCB Layout Editor) and open Preferences > Manage Footprint Libraries. Then, press “Browse Libraries…” and select all .pretty folders which you want to add before pressing “OK”

Screenshot from 2018-08-13 22-38-44
Picture 4. Adding Library Footprint to create PCB Layout

That’s all about adding libraries to KiCad. Next time, I’ll talk about creating a simple PCB design using KiCad. Have fun trying KiCad!

Installing KiCad: Open Source PCB Designer Suite (English)

KiCad is an open-source software to create schematics, PCB layouts, and Gerber. KiCad can be used in Windows, Linux, and macOS, and licensed under GNU GPL v3. KiCad is made by Jean Pierre Charras, a professor in Grenoble University. KiCad is also sponsored by CERN and had several KiCad developments done under CERN employees. If you’re interested to develop KiCad, you can do it through CERN

I’m interested to try this application to do simple projects as a hobby. KiCad became the optimal choice because it is open source, which allows anyone to use it. Aside from that, KiCad also has a library which is updated weekly, accessible via GitHub. Adafruit which produces many modules and even development boards also used KiCad to create their products

Ubuntu Installation

I tried to install it using Ubuntu 18.04 this time, you can see the installation manual from this link: KiCad Ubuntu

I’ll explain how to install KiCad PCB v5 in Ubuntu 18.04. First, you need to add this ppa:

# add-apt-repository -y ppa:js-reynaud/kicad-5

(Ubuntu 16.04) If you’re using Ubuntu 16.04, use apt-get update before installing KiCad:

# apt-get update
# apt-get install kicad

You will download around 391MB using that command, and installing KiCad will take around 4,970MB disk space. After that’s done, you can open KiCad through a terminal or a launcher

Screenshot from 2018-08-09 19-56-37
Picture 1. The terminal after installing KiCad and its application display

I plan to start a series of articles using KiCad. I’ll talk about adding library through KiCad GitHub after this. Have fun trying KiCad!
